Product Name: Zenith Heavy-Duty Floor Hinge
Material: Stainless Steel 304
Application: Commercial & Architectural Doors (Single / Double Action)
Technical Description:
The Zenith 300 kg Floor Hinge is a premium-grade, heavy-duty concealed door control mechanism engineered for high-traffic commercial, architectural, and luxury residential applications. Manufactured from SS 304 stainless steel, it offers exceptional corrosion resistance, mechanical strength, and aesthetic durability, making it ideal for both indoor and outdoor installations.
Designed to support doors weighing up to 300 kg, the hinge ensures smooth, controlled opening and closing through a precision hydraulic mechanism. It features adjustable closing speed and latching speed control, delivering optimal performance for frameless glass, timber, and metal doors.
Key Features:
Load Capacity: Up to 300 kg
Material: SS 304 stainless steel body & cover plate
Door Type: Single or double action, up to 1500 mm wide
Opening Angle: 90° / 105° / 120° stop or non-hold open option
Closing Control: Dual-stage hydraulic speed adjustment
Durability: Tested to over 500,000 cycles
Corrosion Resistance: Suitable for coastal and high-humidity environments
Installation: Concealed in floor for clean aesthetics and security
Standards & Certifications:
Complies with EN 1154 and ANSI/BHMA A156.4 performance standards
Fire-rated options available (upon request)
Applications:
Luxury hotels & resorts
High-end residential towers
Shopping malls & commercial complexes
Corporate offices & public buildings
