The Zenith Wired Remote Water Meter uses photoelectric direct reading technology for accurate, error-free readings without batteries. Powered directly by collection equipment (RS-485 DC 12V or M-BUS DC 36V), it ensures long service life with IP65 protection and nodular cast iron construction.
Supporting RS-485 and M-BUS communication protocols, this meter enables real-time data collection and integrates with WeChat and other platforms. The design provides strong anti-interference capability and convenient installation for reliable water management.
Models: DN15, DN20, DN25
Communication: RS-485 / M-BUS (Optional)
Power Supply: RS-485: DC 12V, M-BUS: DC 36V
Protection Level: IP65
Base Material: Nodular Cast Iron
Sampling Method: Photoelectric Direct Reading
Temperature Level: T30 (Cold), T90 (Hot)
Q3/Q1 Ratio: 100
Flow Rates (Q3): 2.5 m³/h (DN15), 4.0 m³/h (DN20), 6.3 m³/h (DN25)
