The Zenith Volumetric Piston Water Meter delivers exceptional measuring accuracy with a starting flow of 2 L/h or less, meeting ISO 4064 Class C and R160 standards. Its register wheel is sealed with special liquid to ensure clear, long-lasting readings, while the high-quality mechanism provides stable, reliable performance in precision industrial settings.
Designed for maximum flexibility, this meter can be installed in vertical, horizontal, or inclined positions to suit various applications. Available in brass or nylon plastic construction with dry or wet type options, it supports both cold and hot water measurement with customizable accuracy classes (R160/R200/R250) and optional pulse output for remote monitoring. Specifications
Models: LXH-15, LXH-20, LXH-25, LXH-32, LXH-40
Body Material: Brass, Nylon Plastic
Register Type: Dry Type / Wet Type
Accuracy Class: R160, R200, R250
Permanent Flow Rate (Q3): 2.5 m³/h (DN15), 4.0 m³/h (DN20), 6.3 m³/h (DN25), 10.0 m³/h (DN32), 16.0 m³/h (DN40)
Minimum Flow Rate (Q1): 0.015 m³/h (DN15) to 0.1 m³/h (DN40)
Water Pressure: ≤1.0 MPa or 1.6 MPa
Temperature Class: T50 (Cold ≤50°C), T90 (Hot ≤90°C)
Reading Range: 0.0001 - 9999 m³
Installation Position: Horizontal / Vertical / Incline
Pulse Output: Optional
