The Zenith Rotary Wing Type Single Flow Water Meter features a single-jet rotary vane design with a dry dial and magnetic drive system that resists exterior magnetic interference. Its vacuum-sealed register prevents fogging and ensures clear, long-term readability, while the rotatable register allows for easy viewing from any angle.
Available in copper, iron, plastic, or stainless steel construction, this compact and lightweight meter offers optional remote pulse output (10, 100, or 1000 liters/pulse). With high-quality materials ensuring stable performance, it is suitable for both cold water (0-40°C) and hot water (0-90°C) applications. Specifications
Models: DN15, DN20, DN25 (Class B)
Nominal Flow (Q3): 2.5 m³/h (DN15), 4.0 m³/h (DN20), 6.3 m³/h (DN25)
Transitional Flow (Q2): 0.12, 0.20, 0.28 m³/h
Minimum Flow (Q1): 0.03, 0.05, 0.07 m³/h
Overload Flow (Q4): 3, 5, 7 m³/h
Reading Range: 0.0001 - 99999 m³
Materials: Copper, Iron, Plastic, Stainless Steel (Optional)
Pulse Output: Optional (10L, 100L, or 1000L per pulse)
Working Pressure: ≤1.0 MPa
Temperature Range: 0-40°C (Cold), 0-90°C (Hot)
