The Zenith Prepaid Bluetooth Water Meter features a built-in Bluetooth module for convenient wireless recharge and payment via mobile apps, eliminating the need for complex wiring. It includes a liquid crystal display (LCD) that intuitively shows water purchase amount, remaining balance, cumulative consumption, and valve status.
Designed with IP68 protection and a brass body, this meter ensures safety and durability in complex environments. It features automatic valve closing for low battery, low water levels, or magnetic attacks, along with a monthly self-inspection function to prevent valve rusting.
Models: DN15, DN20, DN25
Communication: RF card-Bluetooth
Power: DC 3.6V Battery (ER17450)
Standby Current: ≤10uA
Protection Level: IP68
Base Material: Brass
Sampling Method: Pulse
Temperature Level: T30 (Cold), T90 (Hot)
Q3/Q1 Ratio: 100
Electronic Reading: 0.01-99999.99
Flow Rates (Q3): 2.5 m³/h (DN15), 4.0 m³/h (DN20), 6.3 m³/h (DN25)
