The Zenith IoT Remote Water Meter is a smart water metering solution designed for accurate water measurement and remote monitoring. Its modular design allows easy separation of the communication module and metering unit, helping improve reliability, maintenance, and future upgrades.
It supports multiple communication methods, including NB-IoT, LoRa, and other optional communication networks, allowing convenient integration with different water management and monitoring platforms. With low power consumption, IP68 protection, efficient data processing, and multi-platform support, it is suitable for residential, commercial, and water management applications.
Model: DN15 / DN20 / DN25
Permanent Flow Rate (Q₃):
DN15: 2.5 m³/h
DN20: 4.0 m³/h
DN25: 6.3 m³/h
Transitional Flow Rate (Q₂):
DN15: 0.04 m³/h
DN20: 0.064 m³/h
DN25: 0.1 m³/h
Minimum Flow Rate (Q₁):
DN15: 0.025 m³/h
DN20: 0.04 m³/h
DN25: 0.063 m³/h
R: 100
Electronic Reading: 0.01–99999.99
Communication: NB-IoT, LoRa, NB-IoT/LoRa (optional)
Supply Method: Battery powered, ER26500, 3.6V, 8700mAh
Standby Current: ≤10µA
Protection Level: IP68
Sampling Method: Pulse
Temperature Level: Cold Water T30 / Hot Water T90
Base Material: Nodular Cast Iron
